BIBI 33BL Combo
Compact Lifts
TYPE
Compact Lifts
MODEL SERIES
BIBI
Product Overview
Specifications
Standard Equipment
- Tracked scissor lift
- Bi-leveling tracks
- Dynamic leveling
- Pro-Active leveling
- Easy Drive System
- Honda and Lithium Battery Pack
- Non marking tracks
- Basket capacity – 661lbs
- Expandable basket
- Remote control with lanyard
- Direction control
Performance
| Working height | 32ft9in |
| Max height basket floor | 26ft3in |
| Basket load-max | 661lbs |
| Basket dims | 4ft11in x 2ft8in |
| Basket leveling | Automatic |
| Leveling -Front | +/- 16° |
| Leveling – Rear | +/- 25° |
| Side Leveling | +/- 15° |
Dimensions
| Height – folded railings | 6ft8in |
| Height – tracks wide position | 8ft6in |
| Height – tracks narrow position | 9ft7in |
| Length | 7ft5in |
| Width tracks | 4ft9in – 5ft8in |
| Weight (approx) | 6373 lbs |
| Tracks | Bi leveling |
| Drive gradeability | 25° |
| Side Slope | 21° |
| Hydraulic controls | Proportional |
| Dynamic Leveling | Standard |
| Pro-Active Leveling | Standard |
| Direction control | Yes |
| Inclination control | Automatic |
| Ground emergency | Yes |
Power Source
| Honda | Standard |
| Lithium Battery Pack | Standard |
| Diesel Hatz 1B40 | Optional |
Reach Envelope
